- Brand: Lincat
- Range: Panther
- Series: SuperPass
- Power Type: Electric
- Unit Type: Free-standing
- Available in UK Only: No
- UK Warranty: 2 Years Parts and Labour Warranty
- Export Warranty: Contact your local dealer
- GTIN: 5056105109853
**Power and Performance**
- Total Power kW: 16.52
- IP Rating: IP24
- Temperature Control: Top: Mechanical; Bottom: Electronic
**Key Specifications**
- Drain Location: Rear-mounted
- Number of Shelves included: 1
- Number of Shelf Positions: 1
- Pot Type: Gastronorm
- Type of Heat: Wet/Dry
- Heated Base: Yes
- Heated Gantry: Yes
- Static or Mobile: Mobile
**Capacity**
- Gastronorm Capacity: 6 x GN1/1
- Plate Capacity: 556
**Weights and Dimensions**
- Unit Height (External) mm: 1,908
- Unit Width (External) mm: 2,273
- Unit Depth (External) mm: 1,000
- Height (Internal) mm: 405
- Width (Internal) mm: 2,000
- Depth (Internal) mm: 825
- Shelf Dimensions Width mm: 1,938
- Shelf Dimensions Depth mm: 690
- Net Weight Kg: 250
**Supply Connections**
- Requires Installation: Yes
- Requires Electrical Supply: Yes
- UK 3 Pin Plug: No
- Requires Hardwiring: Yes
- Electrical Supply Rating Watts: 16,520
- Three Phase Amps: L1=23.9; L2=23.9; L3=23.9
- Three Phase Voltage: 400
