- Brand: Lincat
- Range: Opus 800
- Power Type: Gas
- Gas Type: Propane Gas
- Unit Type: Free-standing
- Available in UK Only: No
- UK Warranty: 2 Years Parts and Labour Warranty
- Export Warranty: Contact your local dealer
- GTIN: 5056105103172
**Power and Performance:**
- BTU per Hour: 109,184
- Total Power kW: 32.0
- Temperature Range °C: 90-190
- IP Rating: IP24
- Temperature Control: Mechanical
**Key Specifications:**
- Number of Baskets: 2
- Number of Tanks: 2
- Gravity Filtration: No
- Pumped Filtration: Yes
- Drain Location: Through the body
**Capacity:**
- Product Output per Hour: 44kg chips - 12mm [frozen], 64kg chips - 12mm [chi]
- Capacity Litres: 2 x 14.0
**Weights and Dimensions:**
- Unit Height (External) mm: 1,070
- Unit Width (External) mm: 600
- Unit Depth (External) mm: 800
- Net Weight Kg: 144.3
**Supply Connections:**
- Requires Installation: Yes
- Requires Electrical Supply: Yes
- UK 3 Pin Plug: Yes
- Requires Hardwiring: No
- Electrical Supply Rating Watts: 200
- Single Phase Amps: 1.0
- Single Phase Voltage: 230
- Gas Connection BSP: 1/2"
- Gas Consumption at full rate Propane m³ per Hour: 2.29
- Gas Pressure Propane mbar: 37.0
- Total heat input at full rate Propane kW: 32.0
- Total heat input at full rate Propane BTU per hour: 109,189
