How to Mount and Configure Overlap for Combisteel 7059.0005 Cold Room Curtains

To install the Combisteel 7059.0005 strip curtain, you must first mount the 110cm suspension rail above the doorway.

Applies to

This guide applies to the Combisteel 7059.0005 cold room strip curtain.

You must gather a ladder or kitchen steps before beginning the installation.
You will need a pen, pencil, or marker to mark the drill holes.
You must prepare a drill to create the mounting holes.
You must acquire the appropriate screws to mount the suspension rail.
You must note that the mounting screws are not included with the curtain kit.
You will need a Stanley knife or a safety knife to trim the strips later.
You must verify that the attachment point is strong enough to support the weight of the curtains.

You must verify the attachment point is strong enough to support the curtain's weight.
You must exercise caution when using a Stanley or safety knife to trim the strips.

The suspension rail is pre-drilled for either wall or ceiling mounting.

You must decide whether to mount the rail on the wall or the ceiling above the doorway.

When mounting on a wall, you must make sure that the curtains are wider than the door opening.

This extra width ensures better door sealing for the cold room.

When mounting on a ceiling, you must allow the outer curtains to swing freely.

You must verify that the chosen attachment point is strong enough to support the weight of the curtains.

Verify that the chosen attachment point is strong enough to support the weight of the curtains.
Ensure you have a ladder or kitchen steps ready to reach the mounting area safely.
Check that you have the correct screws for your specific wall or ceiling material.
Remember that the mounting screws are not included with the kit.

The suspension rail has a total length of 110cm.

You must mount this rail directly above the doorway.

You must ensure that the hooks on the rail are hanging downwards.

You will need a pen, pencil, or marker to mark the drill holes accurately.

You will need a drill to prepare the holes for the screws.

You can configure the Combisteel 7059.0005 cold room curtains for either a minimum or maximum overlap.

A minimum overlap provides a forty percent coverage overlap between the strips.

A maximum overlap provides an eighty percent coverage overlap between the strips.

You must hang the first row of strips across the width of the rail before adding the second row.

You will leave specific gaps between the strips in the first row depending on your chosen overlap.

Hang the first row of strips across the width of the rail.
For a minimum overlap of forty percent, leave a gap of three hooks between each strip.
For a maximum overlap of eighty percent, leave a gap of one hook between each strip.
Hang a second row of strips directly over the first row.
Place each strip in the second row over the gaps left in the first row.

The PVC strips will likely be too long once they are initially hung on the rail.

You must wait until all the PVC strips have been laid before cutting them.

You will need a Stanley knife or a safety knife to perform this task.

You must exercise caution when using a Stanley or safety knife to trim the strips.

You will cut the strips to leave a small gap above the floor.

Do not proceed if the attachment point cannot support the weight of the curtains.
