The Blizzard BIM230 is sold as a pre-made bundle of both machine and matching bin, producing 227 kg of cubed ice per 24 hours with 175 kg storage capacity.
Applies to
This explainer applies specifically to the Blizzard BIM230 commercial high capacity ice machine and storage bin bundle.
Before you start
- Confirm access to a dedicated 13-amp power supply to support the unit's 1050W power consumption.
- Ensure the installation area accommodates bundle dimensions of 1755 mm in height, 770 mm in width, and 860 mm in depth.
- Verify that floor surfaces can safely support the unit weight of 120 kg.
Safety warnings
- Handle and position the unit safely given its 120 kg weight and the use of R290 refrigerant.
Technical Specifications and Capacities
The Blizzard BIM230 produces 227 kg of cubed ice every 24 hours.
The matching storage bin provides a dedicated holding capacity of 175 kg of ice.
The unit dimensions are H1755 mm by W770 mm by D860 mm with a total weight of 120 kg.
The appliance requires a 13-amp electrical supply and operates with a power usage of 1050W.
Operational Features and Construction
Both the machine and bin feature high-grade stainless steel and black ABS construction.
The unit provides fully automatic operation with low water consumption and fast 10 to 20 minute cycle times.
Standard operational features include easy-to-use electronic controls, integrated LED lighting, and a cleaning function cycle.
Optional extras available for applicable units include a water filter kit and a drain pump.
