The Blizzard BCC1 is a compact single-door counter refrigerator offering 109L gross capacity, an operating temperature range of +2°C to +8°C, and dedicated design features for straightforward sanitisation.
Applies to
This guide applies directly to the Blizzard BCC1 single-door compact counter refrigerator.
Before you start
- Ensure the counter connects to a standard 13-amp power supply and operates using its R600a refrigeration system.
Safety warnings
- The unit utilises R600a refrigerant and connects to a 13-amp electrical supply.
Technical and Operating Specifications
The unit measures 876 mm in height, 435 mm in width, and 700 mm in depth, with a total weight of 47 kg.
It operates with a 120W power rating, consumes 629 kWh per annum, and includes 35mm insulation.
Temperature management is handled by an integrated digital controller maintaining a range between +2°C and +8°C.
Internal storage includes one adjustable GN1/1 shelf behind a self-closing door featuring a dwell position.
The cabinet is supplied with adjustable feet as standard and provides an option for castors.
Hygiene and Cleaning Design Features
Both the exterior and interior are constructed from high grade AISI 304 stainless steel, which resists oxidising acids and makes surfaces easy to sanitise.
Internal corners are rounded to aid thorough routine cleaning inside the cabinet.
The door gasket is easily removable and replaceable to support hygiene maintenance.
The refrigeration system includes an easily removable condenser filter designed for routine cleaning.
